Heavy Duty Snap-On Mechanism Ball Bearing Slide

HA 5313 Heavy Duty Snap-On Mechanism Ball Bearing Slide

The HA5313 is a 3-section ball bearing slide designed for applications that require high load capacity and reliable performance. Its key feature is the heavy-duty snap-on mounting system, which simplifies installation and drawer removal compared with conventional mounting methods. Once installed, the mechanism provides a secure connection between the drawer and the slide, helping ensure smooth operation and long-term durability in demanding office, storage, and furniture applications.

Built to perform under extreme loads, this slide boasts an impressive 120kg (264 lbs) capacity per pair. This remarkable strength comes from its rugged construction, featuring 2.0mm thick cold-rolled coil steel on all three sections for uniform durability and resistance to bending. The smooth and silent operation is guaranteed by the ball bearing system, which ensures full extension and effortless access to the entire drawer contents.

The slide is available in standard lengths from 12 to 30 inches (305-760mm), with special lengths available upon customization. It undergoes a surface treatment of zinc plating with a blue or black finish, providing excellent corrosion resistance for a long service life in demanding environments.

The snap-on mounting design simplifies installation and drawer removal, helping improve assembly efficiency while ensuring a secure and reliable connection.

Made from 2.0 mm thick cold-rolled steel and tested with a 48-hour 5% salt spray test for enhanced durability and corrosion resistance.

The ball-bearing action can create a quiet environment at work.

Nylon buffer can reduce the direct contact between the outer and the inner channel.

Brand Name	HVPAL	Material	Cold Rolled Steel
Model Number	HA5313	Finish	Clear Zinc Electroplate
Loading capacity	120KG/450MM(18'')	Height	53mm
Length	12"-30" (305-760mm)	Application	Kitchen, Industrial drawers, Outdoor, Office Building, Hospital, Mall, Sports



APPLICATIONS

FAQ

Q1: Are you a manufacturer or a trading company?

A: We are a professional drawer slide manufacturer with our own production facilities and quality control system. This allows us to maintain consistent product quality, competitive pricing, and reliable delivery for customers worldwide.

Q2: What after-sales support do you provide?

A: Customer satisfaction is important to us. If you encounter any quality issues after receiving the goods, please contact us with details and photos. Our team will respond promptly and work with you to find a suitable solution.

Q3: Which markets do you mainly serve?

A: Our products are exported to customers across Europe, North America, Southeast Asia, the Middle East, and other regions. We have established long-term partnerships with furniture manufacturers, cabinet makers, and industrial equipment companies.
