220kg Heavy Duty Drawer Slide Rail
Brand Name: HVPAL
Material: Cold Rolled Steel
Model Number: HA7103
Finish: Clear Zinc Electroplate/electrophoresis black
Loading capacity: 227KG/450MM(18'')
Height: 71mm
Length: 10"-60" (254-1524mm)
Application: Kitchen, Industrial drawers, Outdoor, Office Building, Hospital, Mall, Sports
Description
HA7603 227kg heavy duty drawer slide rail
The details of the HA7603 slide rail are as follows,
-- Load rating: 227kg/pair(18")450mm
-- Extension: 100% full time extension
-- Material: hardened cold rolled steel
-- Width: 76 mm
-- Steel plate thickness: 2.5*2.5*2.5mm

3-Fold Slides. Enable the slides to extend fully.

Constructed with 2.5 mm thickness cold-rolled steel. By using 5% salt spray for 48 HRS

The ball-bearing action can create a quiet environment at work.

Nylon buffer can reduce the direct contact between the outer and the inner channel.
APPLICATIONS




Load Capacity: Supports up to 227kg (500lbs) per pair at 450mm length, ideal for toolboxes, warehouse storage, and heavy cabinets1
Full Extension: 100% travel ensures complete access to drawer contents
Material: Constructed from hardened cold-rolled steel with corrosion-resistant finishes (e.g., blue zinc plating)
Design: Three-fold ball-bearing mechanism for smooth operation and durability (tested to 80,000 cycles)
Dimensions: Standard 76mm width, lengths ranging from 254mm to 1524mm (10–60 inches)
Applications: Suited for industrial drawers, ATM compartments, and RV storage
This robust slide combines strength, precision, and longevity for demanding environments.
